Select Yes to reset attributes and then OK.If the number entered was worn, select undo and try another number. By entering in a lower number the similar colours are grouped together. The current number of colours found in this scan is 255. From Bitmaps Colour main pull down menu select Reduce number ….The number of colours can be reduced by automatically linking like colours together by using the command Reduce number. When the image is scanned in it has picked up several colours. The bitmap was scanned in at 300 dpi and is a very rough pencil sketch of the intended design. Change the image height to 50 mm and the origin to the centre and press OK.Ī new model has been created which contains a scanned in bitmap image.From D:\users\trainingArtCam Data, select 300dpi-locket.jpg and press Open.Locket ExampleĪ flat model needs to be opened to gain access to the JewelSmith commands Trace VectorsĬoloured Pictures can be used to trace vectors. Pictures are loaded directly into ArtCAM by using File Open and selecting the Picture. Pictures (*.gif *.tif *.jpg or *.bmp) can be turned into ArtCAM reliefs by either assigning shapes to the selected coloured areas or by creating a vector from the colours and using the vectors with the shape editor. ArtCAM has the power to link colours together temporarily which enables you to define different areas, to make a vector from, without destroying the picture. The higher the resolution is, the smaller the squares, giving a smoother relief.ĪrtCAM can also generate vectors of the boundaries of the selected colour, which enable you to use the vector generation methods to generate a smoother relief. This form of relief generation breaks the colours into tiny squares, dependent on the resolution, which are given a height. Pictures can be turned into reliefs by giving assigning shapes to the selected colour. Coloured Pictures can be generated or edited within ArtCAM using the Bitmap toolbar or they can be loaded in using any of the following formats bmp.
